Key features
- Versatile Imaging Capabilities: Genoray Papaya 3D combines 3D CT, panoramic, and optional cephalometric imaging to comprehensively address all diagnostic requirements.
- Award-Winning Design: Recognized for its exceptional design, Papaya 3D received awards from the Korea Ministry of Design Motivation and KEIT’s Design Grand Prize, reflecting its innovative and aesthetically pleasing features.
- Dedicated CMOS Flat Panel Sensors: Equipped with three dedicated CMOS flat panel sensors for Pano, Ceph and 3D imaging needs, ensuring long-lasting performance and sensor longevity. No overload on a single sensor for both 2D and 3D imaging.
- Scout Mode for Error Avoidance: Scout mode facilitates accurate positioning, minimizing errors during image acquisition.
- Smart Metal Artefact Removal (SMARF): Enhanced image clarity through intelligent metal artefact removal technology.
- 2Sec Ceph (plus): Innovative sensor technology enables the acquisition of cephalometric images in just 2 seconds, reducing the risk of patient movement and improving image quality.
- Zero Error Imaging: Reliable and accurate imaging capabilities for precise implant planning.
- Flexible Scan Modes: Choose from three scan modes: Normal, Fast, and HD, catering to diverse clinical needs.
- Wide Range of Field of View (FOV): Papaya 3D offers 19 FOV options, from 4×5 to 16×14 suitable for a variety of dental practices.
- Optimized Voxel Sizes: Specific FOVs with voxel sizes such as 75, 100, 150, and 200 microns cater to specialized cases like Endodontics, Periodontics, TMJ, and Maxillofacial procedures.
- Rapid Scanning and Reconstruction: Efficient scanning with a scanning time ranging from 7.7 to 14.5 seconds, coupled with reconstruction in less than 1 minute.
- Model Scanning Capability: Papaya 3D (+) can scan both impressions and plaster casts, providing digitized models in STL format for immediate use, reducing the need for physical plaster casts.
- DICOM Compatibility: Easily share images in DICOM® format, supporting open software architecture for software solutions tailored to your needs.
- Robust and Secure Design: Sealed base and columns protect against pests like rats, lizards, and cockroaches, preventing wire cutting and short-circuiting.
- Easy Installation: Self-standing design eliminates the need for drilling into walls or floors, ensuring hassle-free setup.
- Wheeled Mobility Accessible: Designed to be Wheeled Mobility accessible for patient convenience and inclusivity.
Technical Specification
Exposure Time
• Panoramic: 9–17 sec
• Cephalometric: 4–12 sec
• CT: 7.7 / 14.5 sec
• Field of View (FOV): Ø35 × 40 mm ~ Ø140 × 140 mm
• Programs: 19 Programs
• Voxel Size: 75–400 µm Adjustable
• Focal Spot: 0.5 mm
• Target Angle: 5°
• Tube Voltage: 60–90 kV
• Tube Curren: 4–12 mA
• Line Voltage: 220V, 50/60 Hz
Pixel Pitch
• CT: 100 × 100 µm
• Panoramic: 75 × 75 µm
• Cephalometric: 75 × 75 µm
Active Area
• CT: 130.2 × 128 mm
• Panoramic: 152 × 6.45 mm
• Cephalometric: 228 × 6.45 mm
Pre-Installation Guide
Click here to open PDF in new tab
Packaging
- Genoray Papaya 3D Plus Dental CBCT
Warranty
- Manufacturer/Importer warranty of 5 Years as applicable for this product.
- Warranty does not apply against any physical damage to the product.
FAQS
1. What imaging modalities does Papaya 3D Plus support?
It supports 3D CBCT imaging, panoramic imaging, and cephalometric imaging, making it suitable for comprehensive dental diagnostics.
2. What is the exposure time for panoramic scans?
The panoramic exposure time ranges from 9 to 17 seconds, depending on the selected imaging program.
3. Does the system support cephalometric imaging?
Yes, Papaya 3D Plus includes cephalometric imaging with an exposure time of 4–12 seconds.
4. What is the Field of View (FOV) range of the system?
The system offers a flexible FOV range from Ø35 × 40 mm to Ø140 × 140 mm, suitable for various clinical applications.
5. How many imaging programs are available?
Papaya 3D Plus provides 19 imaging programs to accommodate different diagnostic requirements.
