Key FEATURES
• CMOS Sensor Technology delivers clear, high-resolution diagnostic images
• 4096 Grey Levels (12-bit) ensure enhanced contrast and precise interpretation
• 5 lp/mm Minimum Resolution provides sharp, detailed image quality
• No Control Box Design enables simple workflow – Position. Expose. View.
• Pre-Programmed Filters (Perio, Endo, DEJ) allow optimized image enhancement
• Customizable Sharpness Control helps adjust image appearance as per clinical need
• Waterproof & Airtight Construction ensures long-lasting durability
• USB 2.0 High-Speed Connectivity supports quick installation & reliable data transfer
• Broad Software Compatibility integrates with most imaging & practice management systems
Technical Specification
- Technology: CMOS
- Scintillator: Optical Fiber
- Sensor Matrix: 1168 × 1562 pixels
- Active Surface Dimensions: 22.2 × 29.6 mm
- Sensor Dimensions: 27.6 mm (W) × 37.7 mm (H) × 7.3 mm (D)
- Weight: 65 g
- Grey Scale: 4096 grey levels (12-bit)
- Input Voltage: 5V DC (USB interface)
- USB Interface: USB 2.0 High Speed
- True Image Resolution: 16 LP/mm
- Sensor Plate Thickness: 7.3 mm
Packaging
Package Dimension (cm): 27 x 20 x 11
• RVG 5200 Intraoral Sensor – Size 2
• USB 2.0 Connection Cable (Type A Plug)
• Sensor Holder
• Instructions Manual
Installation
This product is self-installable; technician support is available on a paid basis if required.
Warranty
- 5 Year Warranty against the manufacturing defect for the sensor.
- Physical Damage on Sensor is not covered under warranty.
FAQs
Q: What makes the Carestream RVG CS 5200 suitable for different procedures?
A: The 3 pre-programmed modes (Perio, Endo, Dentino-enamel junction) optimize image contrast for specific diagnostic needs.
Q: Is the sensor comfortable for patients?
A: Yes, the sensor is 20% thinner and designed for easy placement, ensuring patient comfort.
Q: How durable is the sensor?
A: The RVG CS 5200 is fully waterproof and dust-resistant, offering long-term reliability under rigorous use.
Q: Can I customize the image settings?
A: Absolutely! The system allows user-defined image processing tools for enhanced diagnostic accuracy.
Q: Is it easy to use in a busy dental practice?
A: Yes, its plug-and-play workflow eliminates the need for a control box, making it simple and efficient to use.
Q: Is Carestream RVG the same as Kodak RVG?
A: Carestream Dental evolved from Kodak’s Health Group. While Kodak continues in other imaging sectors, dental imaging systems like RVGs are now developed and marketed by Carestream. Many dentists still use the terms interchangeably.
Q: What is the Carestream RVG price in India?
A: The Carestream RVG price in India varies depending on the model, sensor size, warranty, and supplier. For example, the Carestream RVG CS5200 Digital Intraoral Sensor – Size 1—one of the most popular entry-level RVG systems—typically costs around ₹89,000 to ₹1,30,000 in the Indian market.
