Key Highlights
- Material Adapter Compatibility: Features a FIXED C-CLAMP, emphasizing ease of use and precision.
- Open Architecture Restoration: Allows for milling a wide range of applications with accuracy and simplicity. It supports various CAD/CAM software, scanners, and materials, offering flexibility and freedom in operations.
- Simplified Operation: An intuitive Virtual Machine Panel (VPanel) manages tool swapping with the intelligent Tool Control (ITC) function, conducts machine diagnostics, and ensures automatic calibration.
- User Replaceable Spindle: Enables quick and easy spindle replacement by the user, eliminating the need for technician assistance or special tools.
- 52Di Model C-Clamp Adapter: Designed for cost-effective milling, allowing up to 31 single units per material disc.
- Increased Milling Capabilities: Features a 15-station Automatic Tool Changer (ATC) and auto-adjusted air pressure for continuous milling, responding to CAM software data for optimal air volume adjustment.
- 5-Axis Milling: A ball screw-driven system enables simultaneous rotation and tilting of discs for deep undercuts and milling of large arch restorations with precision.
- Clean and Efficient Milling: Equipped with an auto-start dust collection system for cleanliness and a built-in ionizer to reduce static when milling PMMA.
Technical Specification
- Cuttable Material: Zirconia, Wax, PMMA, and more
- Workpiece Weight: Up to 1.87 lbs (850 g)
- Workpiece Dimensions: Various sizes, max height 35mm
- Number of Adapters: 6 housed
Operating Parameters:
- Operating Speed: 6 to 1,800 mm/min
- Spindle Motor: Brushless DC
- Spindle Speed: 6,000 to 30,000 rpm
- Rotary Axis Travel Angle: A: ±360°, B: ±30°
- Burs Housed: 15
- Attachable Bur: 4 mm diameter, 40-55 mm length
- Compressed Air Compatibility: 0.2 MPa
Control and Interface:
- Interface: USB
- Control Command Set: RML-1, NC code
Power Requirements:
- Voltage: AC 100 V, 50/60 Hz
- Power Consumption: Approx. 200 W
Operating Noise:
- Operating Noise: 70 dB(A) during operation, 45 dB(A) in standby mode
Dimensions and Weight:
- Dimensions (W x D x H): 34.6 x 26.0 x 23.6 inches
- Weight: 231.5 lbs. (105 kg)
Installation Environment:
- Specific conditions outlined
Included Items:
- Various tools, software, accessories
Operating System:
- Operating System: Windows 7/8/8.1/10
Disclaimer Product configurations, features, and specifications are subject to change based on the original manufacturer’s design and supply. Certain accessories or attachments may not be included in the standard offering and can vary by model or production batch. We recommend confirming all required features at the time of purchase. Requests for additions post-delivery will be considered based on availability and feasibility, and may incur additional costs.
